5V Relay Module 4 Channel Active Low Trigger

Overview of 5V 4-Channel Relay Module (Active Low Trigger)

A 5V 4-channel relay module is a versatile component used in various electronic projects, particularly for controlling high-voltage devices with low-voltage signals. This module typically features four relays that can be triggered by a low-level signal, meaning that the relay activates when the input signal is at 0V.

Key Features

• Active Low Trigger: The module operates on an active low trigger principle, meaning that the relay will turn on when the input signal is low (0V) and turn off when the input signal is high (5V).
• Opto-Isolation: Many of these modules include opto-isolation, which helps protect the microcontroller from high voltages and noise from the relay 1.
• Relay Specifications: Each relay can typically handle loads of up to 10A at 250VAC or 30VDC, making it suitable for controlling various devices such as lights, motors, and other appliances.
• Flexible Input Options: Input signals can be connected through screw terminals or pin headers, providing flexibility in how the module is integrated into a project 2.

Wiring and Usage

To use a 5V 4-channel relay module, you will typically connect it to a microcontroller (like an Arduino) as follows:

1. Power Supply: Connect the module to a 5V power supply.
2. Input Pins: Connect the input pins (IN1 to IN4) to the corresponding output pins of the microcontroller.
3. Load Connections: Connect the devices you want to control to the relay’s Normally Open (NO) or Normally Closed (NC) terminals, depending on your application.

Applications

This type of relay module is widely used in:

• Home Automation: Controlling lights, fans, and other appliances remotely.
• Industrial Automation: Automating machinery and equipment.
• Robotics: Managing motors and other high-power components safely.

In summary, a 5V 4-channel relay module with an active low trigger is an essential tool for anyone looking to control high-voltage devices with low-voltage signals, providing safety and flexibility in various applications.
