KBPC606 Bridge Rectifier 2A

Product Attribute
Attribute Value
Average Current
6 A
Bridge Type
Single Phase
Configuration
Single-Phase
Dimensions
15.2 x 15.2 x 6.4 mm
Diode Type
Bridge Rectifier
Forward Current
6 A
Forward Voltage
1.1 V
Height
0.252″ (6.4mm)
Length
0.599″ <19/32> (15.08mm)
Maximum Operating Temperature
+125 °C
Minimum Operating Temperature
-55 °C
Mounting Type
Through Hole
Non Repetitive On State Peak Current
200 A
Number of Pins
4
Package Type
Square Bridge
Peak Current
1 mA
Primary Type
Rectifier
Product Header
Epoxy Single Phase Full Wave Bridge Rectifier
Repetitive Peak Voltage
600 V
Reverse Current
1 μA
RMS Voltage
420 V
Surge Current
200 A
Temperature Operating Range
-55 to +125 °C
Width
0.598″ (15.2mm)

Overview

Features:
Diffused Junction
High Current Capability
High Case Dielectric Strength
High Surge Current Capability
Ideal for Printed Circuit Boards
Plastic Material has Underwriters Laboratory Flammability Classification 94V-O
