This ethernet board is a simple way to give your Arduino or other electronics project a network connection.
Works with all Arduino boards, including UNO, MEGA, and Nano. It has a 25MHz crystal onboard
- With this Ethernet Shield, your Arduino board can be used to connect to internet
- Genuine Microchip’s ENC28J60 SPI ethernet controller and HR911102A RJ45 socket
- Open-source TCP/IP protocol stack as an Arduino library.
- Web client application to use Arduino as a distributed network sensor
Features
- Ethernet LAN Module for Arduino/AVR/LPC/STM3
- ENC28J60 Ethernet chips
- 1×10 PIN, Can be easily mounted with the MCU
- Network Interface: HR911105A
- Supply Voltage: 3.3 V (5V Tolerant DIO)
- 25Mhz crystal oscillator
- Size (L x W x H): Approx. 2.3 x 1.3 x 0.7 inch / 58 x 34 x 17 mm
Related Links
Specifications
- Chip board ENC28J60-I/SO.
- The board 25MHZ crystal.
- The network interface board HR911105A.
- 3.3 V power supply pin.Debug reminder.
- the IP address of the computer to a network segment and module such as IP module 192.168.1.2, IP computer set: 192.168.1.3; 192.168.1 is the 3 section;
cross the network cable connected to the mouth of the computer network module and mouth; (that is, the cable network 1 3,2 cross, and then do not understand that there are pictures Baidu). - the module and the MCU connection should pay attention to the connection of each line is reliable (the surface is not even connected to the good);
and the MCU port IO to confirm that is right. - the program recompile, download, confirm whether to download! STM32 and 51 IO
- size:48 x 18mm
