Product Overview
The STM32F401CCU6 is a high-performance microcontroller from STMicroelectronics, designed for embedded applications that require low power consumption and high processing power. Based on the ARM Cortex-M4 core, it offers a perfect balance of performance and energy efficiency, making it ideal for real-time control applications, industrial automation, consumer electronics, and IoT projects. The STM32 Development Board, featuring the STM32F401CCU6 chip, provides a convenient platform for developing and debugging your applications, with all the necessary debugging functions, including SWD (Serial Wire Debug), for easy programming and troubleshooting.
Key Features
- ARM Cortex-M4 Core: Runs at up to 84 MHz, offering a high-performance processing unit with a rich set of instructions.
- Flash Memory: 512KB of flash memory for storing your applications, programs, and configurations.
- RAM: 96KB of SRAM for efficient data processing and temporary storage.
- Advanced Peripherals: Includes several advanced peripherals, such as UART, SPI, I2C, PWM, ADC, DAC, and more, providing a versatile platform for communication, sensing, and control tasks.
- SWD Debugging Support: Supports Serial Wire Debugging (SWD) for easy debugging, making it simpler to develop, test, and troubleshoot your applications.
- Low Power Consumption: Features multiple low-power modes for energy-efficient operation, making it ideal for battery-powered projects.
- GPIO Pins: Comes with 37 programmable I/O pins for connecting various external components, sensors, and actuators.
- Integrated Voltage Regulator: Allows stable operation at 3.3V.
- Development Ecosystem: Compatible with a wide range of development tools and software platforms, including STM32CubeIDE, STM32CubeMX, and third-party IDEs.
Technical Specifications
- Processor: ARM Cortex-M4 core, up to 84 MHz
- Flash Memory: 512KB
- RAM: 96KB
- GPIO Pins: 37 programmable I/O pins
- Peripherals: UART, SPI, I2C, PWM, ADC, DAC, and more
- Debugging Interface: SWD (Serial Wire Debug) support for debugging and programming
- Power Supply: 3.3V via onboard voltage regulator
- Operating Voltage: 3.3V
- Dimensions: 60mm x 30mm
- Weight: Approx. 20g
Benefits
- High Performance: The ARM Cortex-M4 core provides excellent performance for complex applications requiring real-time processing and multi-tasking.
- Energy Efficient: With multiple low-power modes, the STM32F401CCU6 offers efficient energy consumption, making it suitable for battery-powered systems.
- Rich Peripheral Support: A wide range of peripheral interfaces and communication protocols, such as UART, SPI, and I2C, make it an ideal platform for connecting various external devices.
- Easy Debugging: The built-in support for SWD debugging makes it easier to develop and troubleshoot applications, speeding up the development cycle.
- Versatile Platform: Suitable for a wide range of applications, including industrial control, home automation, robotics, IoT, and more.
- Development Tools Compatibility: Fully compatible with STM32CubeIDE, STM32CubeMX, and other third-party development tools, providing a complete development ecosystem.
Usage Instructions
- Connect the Board: Power the STM32F401CCU6 development board using a 3.3V power supply.
- Install Development Tools: Install STM32CubeIDE or another compatible IDE on your computer.
- Set Up the Debugging Environment: Use a ST-Link or other compatible debugger to connect the development board to your computer for debugging and programming.
- Develop Your Application: Write your application code using STM32CubeIDE or another IDE, and upload it to the STM32F401CCU6.
- Test and Debug: Use the SWD interface to debug your application in real time and troubleshoot any issues.
- Interface with External Devices: Connect various peripherals and sensors to the GPIO pins and use the appropriate communication protocols (UART, SPI, I2C, etc.) to interact with them.
Applications
- Embedded Systems: Ideal for building embedded systems that require real-time control and data processing.
- Industrial Automation: Use the STM32F401CCU6 for controlling machines, sensors, and actuators in industrial environments.
- IoT Devices: Build Internet of Things applications that require connectivity and efficient processing capabilities.
- Consumer Electronics: Use it in consumer electronic devices that need high performance, energy efficiency, and low-cost solutions.
- Robotics: Ideal for controlling robotic systems, with support for multiple peripherals and real-time processing.
- Prototyping: Perfect for quickly prototyping new ideas for embedded applications and devices.
Why Choose the STM32F401CCU6 Development Board?
The STM32F401CCU6 development board offers a powerful and versatile platform for embedded development. With its ARM Cortex-M4 core, extensive peripheral support, and efficient debugging capabilities, it is the ideal choice for applications that require high performance, real-time processing, and low power consumption. Whether you’re working on industrial automation, IoT, robotics, or consumer electronics, the STM32F401CCU6 development board provides everything you need to create reliable and efficient solutions.
