DC Fan 12V (6x6x2cm)

DC Fan 12V (6x6x2cm)

Overview

A DC fan with dimensions of 6x6x2 cm (or 60mm x 60mm x 20mm) is a compact cooling solution commonly used in various electronic applications such as computer cases, small appliances, and enclosures. Operating at 12 volts, this type of fan is suitable for applications where efficient airflow and heat dissipation are required.

Specifications

• Voltage: 12V DC
  • Operates at 12 volts, which is standard for many electronic systems, including PCs and 12V power supplies.
• Dimensions: 6x6x2 cm (60mm x 60mm x 20mm)
  • Length: 60 mm
  • Width: 60 mm
  • Height (Thickness): 20 mm
• Power Rating: Typically around 1 to 3 watts (exact specification may vary by model).
  • It’s important to check the specific fan model for its wattage to ensure compatibility with your power supply.
• Connector Type: Common connector types include 2-pin, 3-pin, or 4-pin connectors, depending on whether speed control (PWM) is needed.
• Airflow: Generally measured in Cubic Feet per Minute (CFM) or liters per second (L/s).
  • The airflow rating typically ranges between 20 to 50 CFM for this size fan, but this can vary by specific model.
• Noise Level: Typically rated in decibels (dB).
  • Fans in this size can range from around 20 dB (quiet) to around 30 dB (audible).

Features

1. Compact Size:
   • The 6x6x2 cm dimensions make it ideal for tight spaces where larger fans wouldn’t fit.
2. Energy Efficient:
   • Designed to consume relatively low power while providing adequate airflow.
3. Durability:
   • Many DC fans are built with ball bearings or sleeve bearings, providing durability and a longer operating life.
4. Versatile Applications:
   • Suitable for use in computers, electronic enclosures, cooling for components like Raspberry Pi, medical devices, and more.
5. Easy Installation:
   • Typically includes mounting holes for screws or brackets for simple installation into various enclosures.

Applications

• Computer Cooling:
  • Used in PC cases, graphics card coolers, and power supplies to maintain optimal temperatures and prevent overheating.
• Enclosure Ventilation:
  • Provides airflow in electronic enclosures, maintaining a stable operating temperature for sensitive components.
• Custom Projects:
  • Ideal for DIY electronics and hobby projects, including robotics and homemade devices where space is limited.
• Heat Dissipation:
  • Effective in dissipating heat from power supplies, motors, and other electronic equipment.

Installation Tips

1. Power Supply:
   • Ensure you have a suitable 12V power supply to avoid damaging the fan.
2. Orientation:
   • Install the fan in the correct orientation for optimal airflow (usually marked with an arrow on the frame).
3. Secure Mounting:
   • Use screws or mounting clips to secure the fan, preventing vibration and noise during operation.
4. Check for Clearance:
   • Ensure that there is enough clearance around the fan for unobstructed airflow.

Conclusion

A 12V DC fan with dimensions of 6x6x2 cm is a versatile and efficient solution for cooling needs in compact spaces. Its robust design and energy efficiency make it suitable for a wide range of applications, providing reliable airflow and heat dissipation for various electronic devices. If you have any further questions about specifications, installation, or applications, feel free to ask!
