جهاز اختبار قطع SMD يوني تي UT116A

Name: جهاز اختبار قطع SMD يوني تي UT116A
Brand: UNI-T
SKU: 57826
Price: 1550.00 EGP
Availability: InStock

☆☆☆☆☆ 0.0 (مفيش تقييمات) رمز المنتج: 57826

1,550 ج.م

متاح للطلب

الكمية:

اسألنا - نرد عليك على واتساب

يوصلك خلال 72 ساعة

دفع آمن. نقبل: بطاقة بنكية محفظة إلكترونية الدفع عند الاستلام إنستا باي

يُشترى معاً عادةً

هذا المنتج

جهاز اختبار قطع SMD يوني تي UT116A

1,550 ج.م

الإجمالي

45,700 ج.م

الوصف المواصفات التقييمات (0) الأسئلة الشائعة (0)

عن هذا المنتج

UT116 series SMD tester is a miniaturized and integrated utility model measuring instrument, which can automatically identify components such as resistance, capacitance, diode, etc., with LED, voltage regulator, DCV, on-off and battery power measurement functions. SMD resistance, capacitance, diode (RCD) parameter measurement, is a good helper for electronics factories and electronics maintenance.

Features of UT116 Series SMD Testers

Certifications: CE, UKCA

● 36V DC voltage measurement
● Battery measurement (10mA) (UT116C)

● Zener diode polarity test

● Resistance, capacitance (UT116C: up to 100mF), continuity, diode measurement
● The pen can be rotated by 180, which is convenient for reading and diode/LED

Specifications of UT116 Series SMD Testers

Specifications	UT116A	UT116C
Display count	3000	6000
Resistance	30MΩ	60MΩ
Capacitance	30mF	100mF
Diode test	3V	3.2V
LED/stabilivolt	About 21V/1mA	About 21V/1mA
Continuity test	＜30Ω	＜50Ω
DCV	36V
Battery test		Load current ≈ 10mA
Auto range	√	√
Auto scan identiﬁcation	√
Auto power oﬀ	√	√
General Characteristics
Power	1.5V battery (R03) x 2
Display	39mm x 20mm
Product color	Red and grey
Product net weight	About 80g
Product size	204mm x 33mm x 25mm
Standard accessories	Battery
Standard individual packing	Gift box, English manual
Standard quantity per carton	60pcs
Standard carton measurement	440mm x 420mm x 210mm
Standard carton gross weight	About 7.1kg
