موتور دي سي جيرد 25GA370 12 فولت 60 دورة/دقيقة

25GA370 DC Geared Motor (12V / 60 RPM )

The 25GA370 is a high-torque, low-speed brushed DC motor equipped with a precision all-metal gearbox. This model is specifically optimized for applications requiring smooth, powerful motion and the ability to handle significant mechanical loads. With a high reduction ratio and a rugged 4mm D-shaped shaft, it provides stable and reliable performance for robotics and automation systems where high rotational force is more critical than speed.

Key Features

•


  High-Torque All-Metal Gearbox: Features a 103:1 reduction ratio with wear-resistant metal gears, delivering a rated torque of 1.8 kg.cm.





•


  D-Shaped Output Shaft: The 4mm D-shaped shaft ensures a secure, slip-free connection with wheels, couplers, and mechanical linkages.





•


  Heavy Load Capability: Designed to handle an ultimate load (stall) torque of up to 8.5 kg.cm for demanding startup conditions.





•


  Robust & Compact: The 25mm diameter housing allows for easy integration into compact industrial machinery and robotics joints.





•


  Simplified Wiring: Features clearly marked terminals for easy polarity identification and straightforward DC power connection.




Technical Specifications

Applications

•


  Robotics: Ideal for robotic arm joints, heavy-duty drive systems, and climbing robots.





•


  Security & Smart Home: Used in electronic smart locks, motorized valve actuators, and automatic window openers.





•


  Industrial Automation: Suitable for low-speed conveyor systems and precision sorting mechanisms.





•


  DIY Projects: Perfect for camera pan-tilt heads, heavy-duty sliders, and automated dispensers.




Package Contents

• 1x 25GA370 DC Geared Motor (12V / 60 RPM)

Motor Dimensions (MM)
