Specifications
-
Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.8GHz
-
8GB LPDDR4-3200 SDRAM
-
2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE
-
Gigabit Ethernet
-
2 USB 3.0 ports; 2 USB 2.0 ports.
-
Raspberry Pi standard 40 pin GPIO header (fully backwards compatible with previous boards)
-
2 × micro-HDMI® ports (up to 4kp60 supported)
-
2-lane MIPI DSI display port
-
2-lane MIPI CSI camera port
-
4-pole stereo audio and composite video port
-
H.265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode)
-
OpenGL ES 3.1, Vulkan 1.0
-
Micro-SD card slot for loading operating system and data storage
-
5V DC via USB-C connector (minimum 3A*)
-
5V DC via GPIO header (minimum 3A*)
-
Power over Ethernet (PoE) enabled (requires separate PoE HAT)
-
Operating temperature: 0 – 50 degrees C ambient
* A good quality 2.5A power supply can be used if downstream USB peripherals consume less than 500mA in total.
Getting started with your Raspberry Pi
To get started with your Raspberry:
lhttps://www.raspberrypi.com/documentation/computers/getting-started.html
